Factory Free sample Feedwater Regulating Valve - Piston actuator flush tank bottom valve (Disc type) with handwheel – Hoyee

Factory Free sample Feedwater Regulating Valve - Piston actuator flush tank bottom valve (Disc type) with handwheel – Hoyee Featured Image
  • Factory Free sample Feedwater Regulating Valve - Piston actuator flush tank bottom valve (Disc type) with handwheel – Hoyee

Factory Free sample Feedwater Regulating Valve - Piston actuator flush tank bottom valve (Disc type) with handwheel – Hoyee

Short Description:


Product Detail

Product Tags

Related Video

Feedback (2)

owing to very good support, a variety of high quality merchandise, aggressive costs and efficient delivery, we love an excellent name among the our clients. We are an energetic company with wide market for Put Down Feed Valve , Pneumatic Conveying Butterfly Valve , Self Operated Pressure Regulating Valve , We've been honest and open up. We glance ahead on your pay a visit to and developing trustworthy and long-term standing relationship.
Factory Free sample Feedwater Regulating Valve - Piston actuator flush tank bottom valve (Disc type) with handwheel – Hoyee Detail:

Features 1.This range of manual control tank bottom angle valve is manufactured in integrated structure.

2. Structures with disc opening into the tank and disc opening into the valve.

3. Available with 45° degree outlet angle in the body.

4. A rotation-resistant device is set up to ensure that the valve stem only has straight line motions and no rotation.

5.The protection plate makes for the outstanding erosion resistance and corrosion resistance of the valve body.

6.The sealing surface of the valve seat and the valve disc is made of over laying cemented carbide or painted with tungsten carbide. The auxiliary line sealing guarantee the reliability of the sealing performance.

Main specification and technical parameter

Nominal diameter DN(mm) 25X50 50X80 80X100 80X125 100X125 125X150 150X200 200X250 250X300
Rated flow coefficient Kv 11 43 110 110 170 275 440 690 960
Rated stroke L(mm) 30 40 60 100
Actuator area(cm²) ZMQF 320 600 720 1600
ZSQF 300 415 616 1134
Inherent flow characteristic Quick open
Nominal pressure PN(MPa) 1.6、2、4、5、6.3
Structure Put feed valve、Put down feed valve
Allowable leakge Metal seal IV、V Class
Soft seal VI、Zero leakage
Connection form Flange:HG/T20592-2009RF
Gas source pressure Ps(MPa) ZMQF 0.35
ZSQF 0.4~0.6
Product detail pictures:

Factory Free sample Feedwater Regulating Valve - Piston actuator flush tank bottom valve (Disc type) with handwheel – Hoyee detail pictures
