Pneumatic actuator clamp type rubber lined butterfly valve

Pneumatic actuator clamp type rubber lined butterfly valve

Short Description:

Pneumatic butterfly valve flange type product design, reasonable, simple structure, small volume, light weight, 90 degrees of rotation open and close quickly, operating torque is small, easy to operate, save force dexterity.Pneumatic butterfly valve flange type can be easily installed and maintained in any location.The sealing element can be replaced, and the sealing performance is reliable to achieve zero leakage of two-way sealing, the sealing material is resistant to aging, corrosion and long service life.


Product Detail

Product Tags

Pneumatic butterfly valve flange type has good flow control characteristics.Pneumatic butterfly valve flange type is not only widely used in petroleum, gas, chemical industry, water treatment and other general industries, but also used in the cooling water system of qianthermal power station.

Pneumatic actuator clamp type rubber lined butterfly valve specification

Body: Cast Iron, Ductile Iron, Aluminum Stainless Steel,CF8,CF8M,CF3M
Disc: Stainless Steel CF3M,CF3,CF8M, Nylon Coated Ductile Iron,  Double Stainless Steel,2507,1.4529
Stem: 416 Stainless Steel,304 Stainless Steel,316 Stainless Steel
Seats: NBR,EPDM,PTFE,VITON, FKM* Polyurethane
Size: 2″ – 40″ (25mm – 1000mm)
Flange accommodation: EN 1092 PN 6/PN10/PN16
ASME Class 150
AS 4087 PN 10/ PN 16
JIS 5K/10K

Pneumatic actuator clamp type rubber lined butterfly valve  technical parameter

Optional functions of electric actuator double acting, single acting
Optional models of electric actuator AT series, AW series
Air source pressure 2bar-8bar
Nominal diameter DN25mm ~ DN1200mm
Nominal pressure PN1.0MPa~PN1.6MPa
Applicable temperature NBR: -9~+80℃ EPDM: -30~+120℃ PTFE:-30~ +180℃
Connection mode flange type
Body material carbon steel, stainless steel,etc,
Valve plate material Ductile iron,304, 316, 316L, 2507, 1.4529, copper, etc
Seat lining NBR, EPDM, PTFE
Suitable medium water liquid, gas, slurry, oil, etc.
